Type	Collector Current (Max)	Collector Emitter Breakdown Voltage	Vce Saturation (Max.)	Power	Frequency	Package	Packaging	DC Current Gain (hFE)	Mounting Type	Manufacturer


Manufacturer Part Number

Description

Stock

Price in INR

DataSheet

Package

Type

Power

Packaging

Frequency

Manufacturer

Collector Current (Max)

Collector Emitter Breakdown Voltage

Vce Saturation (Max.)

Mounting Type

DC Current Gain (hFE)

2N5401-1

PNP TRANSISTOR 150V 600MA TO-92
SK-2N5401-1

778

1.35 to 3.30

TO-226-3, TO-92-3 (TO-226AA)

PNP

625mW

Bulk

300MHz

Non Specific

600mA

150V

500mV @ 5mA, 50mA

Through Hole

60 @ 10mA, 5V

BC850C

NPN TRANSISTOR 45V 0.1A SOT23
SK-BC850C

612

1.7 to 4.15

TO-236-3, SC-59, SOT-23-3

NPN

250mW

Cut Tape

100MHz

Kexin

100mA

45V

600mV @ 5mA, 100mA

Surface Mount

420 @ 2mA, 5V

BC850B

NPN TRANSISTOR 45V 100MA SOT23
SK-BC850B

384

1.9 to 4.64

TO-236-3, SC-59, SOT-23-3

NPN

250mW

Tape & Reel

100MHz

NXP Semiconductors

100mA

45V

600mV @ 5mA, 100mA

Surface Mount

200 @ 2mA, 5V

PMBTA92

PNP TRANSISTOR HIGH VOLT 100MA 300V SOT23
SK-PMBTA92

340

1 to 2.44

TO-236-3, SC-59, SOT-23-3

PNP

250mW

Tape & Reel

50MHz

NXP Semiconductors

100mA

300V

500mV @ 2mA, 20mA

Surface Mount

25 @ 30mA, 10V

2N5401

PNP TRANSISTOR 150V 600MA TO-92
SK-2N5401

301

1.35 to 3.30

TO-226-3, TO-92-3 (TO-226AA)

PNP

625mW

Bulk

300MHz

Non Specific

600mA

150V

500mV @ 5mA, 50mA

Through Hole

60 @ 10mA, 5V

PMBT3906

PNP TRANSISTOR SW 200MA 40V SOT23
SK-PMBT3906

271

1.5 to 3.66

TO-236-3, SC-59, SOT-23-3

PNP

250mW

Tape & Reel

250MHz

NXP Semiconductors

200mA

40V

400mV @ 5mA, 50mA

Surface Mount

100 @ 10mA, 1V

TBD139

NPN EPITAXIAL SILICON POWER TRANSISTORS 80V TO-126 BD139
SK-TBD139

253

3.5 to 8.54

TO-225AA, TO-126-3

NPN

1.25W

Bulk

Continental Device India Limited

1.5A

80V

0.5V @ 0.5A, 0.05A

Through Hole

250 @ 0.5A, 2V

MMBT5401LT1

PNP TRANSISTOR SS 150V HV SOT23
SK-MMBT5401LT1

250

2.6 to 3.81

TO-236-3, SC-59, SOT-23-3

PNP

225mW

Cut Tape

300MHz

ON Semiconductor

100mA

150V

500mV @ 5mA, 50mA

Surface Mount

60 @ 10mA, 5V

2SC3303-Y(T6L1,NQ)

NPN TRANSISTOR 80V 5A PW-MOLD
SK-2SC3303-Y(T6L1,NQ)

247

23.21 to 40.59

TO-252-3, DPak (2 Leads + Tab), SC-63

NPN

Cut Tape

120MHz

Toshiba Semiconductor and Storage

80V

400mV @ 150mA, 3A

Surface Mount

120 @ 1A, 1V

BC848B

NPN TRANSISTOR 30V 100MA SOT23
SK-BC848B

217

1.9 to 4.64

TO-236-3, SC-59, SOT-23-3

NPN

250mW

Bulk

100MHz

NXP Semiconductors

100mA

30V

600mV @ 5mA, 100mA

Surface Mount

200 @ 2mA, 5V

2N5401-C

TRANSISTOR PNP 150V 0.6A TO-92
SK-2N5401-C

214

1.35 to 3.30

TO-226-3, TO-92-3 (TO-226AA)

PNP

625mW

Bulk

400MHz

Fairchild Semiconductor

600mA

150V

500mV @ 5mA, 50mA

Through Hole

60 @ 10mA, 5V

PMBTA42

NPN TRANSISTOR HIGH VOLT 100MA 300V SOT23
SK-PMBTA42

175

1 to 1.46

TO-236-3, SC-59, SOT-23-3

NPN

250mW

Tape & Reel

50MHz

NXP Semiconductors

100mA

300V

500mV @ 2mA, 20mA

Surface Mount

40 @ 30mA, 10V

CL100S

NPN SILICON PLANAR TRANSISTORS 50V TO-39 L100
SK-CL100S

108

11 to 19.24

T0-39

NPN

Tube

Continental Device India Limited

50V

0.6V

Through Hole

300

BT66T

SIMPLE MELODY GENERATOR
SK-BT66T

7.38 to 15.30

TO-226-3, TO-92-3 (TO-226AA)

Bulk

Non Specific

Through Hole

DTA124EKAT146

PNP PREBIAS TRANSISTORS 200MW SMT3
SK-DTA124EKAT146

4 to 5.86

TO-236-3, SC-59, SOT-23-3

PNP - Pre-Biased

200mW

Tape & Reel

250MHz

Rohm Semiconductor

30mA

50V

300mV @ 500µA, 10mA

Surface Mount

56 @ 5mA, 5V

PMBT2222A

NPN TRANSISTOR SW 600MA 40V SOT23
SK-PMBT2222A

1 to 2.44

TO-236-3, SC-59, SOT-23-3

NPN

250mW

Tape & Reel

300MHz

NXP Semiconductors

600mA

40V

1V @ 50mA, 500mA

Surface Mount

100 @ 150mA, 10V

MMBT4401LT1G

GENERAL PURPOSE NPN TRANSISTOR SS 40V SOT23
SK-MMBT4401LT1G

3.8 to 5.56

TO-236-3, SC-59, SOT-23-3

NPN

225mW

Tape & Reel

250MHz

ON Semiconductor

600mA

40V

750mV @ 50mA, 500mA

Surface Mount

100 @ 150mA, 1V

ULN2004A

NPN DARLINGTON 50V 500MA 16DIP TRANSISTOR 7
SK-ULN2004A

8.5 to 17.63

16-DIP (0.300", 7.62mm)

7 NPN Darlington

Bulk

Texas Instruments

500mA

50V

1.6V @ 500µA, 350mA

Through Hole

MMBTA06

GENERAL PURPOSE NPN TRANSISTOR AMP SOT-23
SK-MMBTA06

2.6 to 3.81

TO-236-3, SC-59, SOT-23-3

NPN

350mW

Tape & Reel

100MHz

Fairchild Semiconductor

500mA

80V

250mV @ 10mA, 100mA

Surface Mount

100 @ 100mA, 1V

PDTA114ET

PNP PREBIAS TRANSISTOR 250MW TO236AB
SK-PDTA114ET

0.91 to 2.60

TO-236-3, SC-59, SOT-23-3

PNP - Pre-Biased

250mW

Tape & Reel

NXP Semiconductors

100mA

50V

150mV @ 500µA, 10mA

Surface Mount

30 @ 5mA, 5V
